igubal® plastic adjusting rings
- Simple assembly
- Stainless steel bolt and nut
- DIN 705 (light series)
- Very light and inexpensive
Part No.
Ø d1 [mm]
Material
Dimensions
Fold
d2 [mm]
40 Fold
S1
SW3 Fold
Weight [g]
16.53 Fold
B [mm]
14 Fold
Ø d1 [mm]
20 Fold
d3 thread
M04 Fold
Mechanical properties
Fold
Max. axial static load, short-term [N]
700 Fold
Max. axial static load, long-term [N]
350 Fold
