drygear® evoloid gearbox incl. stepper motor

Picture 01
Picture 01
Drawing 01
  • Compact motor gearbox unit
  • Planetary gearbox in dry operation
  • Available transmissions: 18:1
  • Max. output torque: 3Nm
  • Stepper motor NEMA 17 including encoder


Part No.
Design
Motor type
Dimensions
Fold
L1 [mm]
21.5 Unfold Fold
L2 [mm]
164.75 Unfold Fold
L3 [mm]
2 Unfold Fold
B1 [mm]
42 Unfold Fold
B2 [mm]
31 Unfold Fold
B3 [mm]
5.5 Unfold Fold
S1
M3 Unfold Fold
S2
M3 STS Schraube Unfold Fold
Ø D1 [mm]
8 Unfold Fold
Ø D2 [mm]
22 Unfold Fold
General properties
Fold
Weight [g]
644.985 Unfold Fold
Mechanical properties
Fold
Transmission
18:1 减速比 Unfold Fold
Backlash [°]
1 Unfold Fold
Rated speed [r/min]
75 Unfold Fold
Rated torque [Nm]
3 Unfold Fold
