Self-aligning ball bearing xirodur® B180, for misalignments, stainless steel balls
- Inner Ø: 10, 12, 20 mm
- Angular movement to compensate misalignments
- Lubricant-free and corrosion-resistant
- Operating temperature: -40 °C to +80 °C
- Ring material: xirodur® B180
- Cage material: PA (polyamide)
- Ball material: stainless steel
Part No.
Ø d1 [mm]
b1 [mm]
Dimensions
Fold
size
1200 Fold
Ø d1 [mm]
10 Fold
Ø d2 [mm]
30 Fold
b1 [mm]
9 Fold
Tolerance of shaft
h6 Fold
General properties
Fold
Ball material
Stainless steel Fold
Density [g/cm³]
1.42 Fold
Colour
White Fold
Max. moisture absorption [Wt.- %]
0.2 Fold
Max. total moisture absorption [Wt.- %]
0.7 Fold
Weight [g]
12.988 Fold
Pivoting
Mechanical properties
Fold
max. speed (rpm)
1800 Fold
Dynamic load capacity [N]
150 Fold
Modulus of elasticity [MPa]
2500 Fold
Flexural strength (at 20°C/68°F) [MPa]
68 Fold
Shore D hardness
77 Fold
Max. pivot angle (α) [°]
3.9 Fold
Thermal properties
Fold
Max. long-term application temperature [°C]
80 Fold
Lower application temperature [°C]
-40 Fold
Chemical resistance
Fold
Alcohol
+ resistant Fold
Greases, oils without additives
+ resistant Fold
Hydrocarbons
+ resistant Fold
Fuels
+ resistant Fold
Strong alkalis
+ to 0 resistant to conditionally resistant Fold
Strong acids
– non-resistant Fold
Diluted alkalis
+ resistant Fold
Diluted acids
0 to – conditionally to non-resistant Fold
