iglidur® PRT-02, slewing ring with integrated spacer ring
- Integrated spacer ring for simple, flush mounting
- No additional machining required on mounting surfaces
- Based on the proven PRT-04 design with spacer ring
- Maintenance-free thanks to lubricant-free plain bearing technology
Part No.
D [mm]
Dimensions
Fold
D [mm]
80 Fold
S2
Ø4,5 Fold
Ø d2 [mm]
60 Fold
d1 [mm]
31 Fold
T1
3x120° Fold
D1 [mm]
70 Fold
h [mm]
11.5 Fold
d [mm]
20 Fold
H [mm]
17 Fold
T2
6x60° Fold
Weights
Fold
Weight [g]
152.5839 Fold
General properties
Fold
Housing material
aluminium Fold
Brand name
iglidur Fold
Requirements
Fold
PRT series
PRT-02 Fold
