dryspin spherical lead screw nut with flange housing | Trapezoidal thread | RH

Picture 01
Picture 01
Drawing 01
  • Material: iglidur J
  • Thread type: high helix thread: higher pitch and travel speed
  • Version: Standard
  • Cylindrical lead screw nut
Part No.
Thread size
Dimensions
Fold
7099dc11-396f-404a-9a29-6daaa99a5835-origin-DRL_TD_SD_SG_EFOM
Thread size
TR10X2 Unfold Fold
Ø d1 [mm]
10 Unfold Fold
b1 [mm]
12 Unfold Fold
General properties
Fold
Weight [g]
7.071 Unfold Fold
Requirements
Fold
Mould-free according to DIN EN ISO 846 Procedure A

Sales Consulting

Total Price

¥350.94
Bulk purchases enjoy unit price discounts
Bracket Price

Quantity (unit)
Unit PriceWithout Tax
¥310.57 /unit
Total PriceWithout Tax
¥310.57
Total taxTax Rate13%
+ ¥40.37
Total Price Includes Tax
¥350.94
