drylin® W WJRM-01-AL | Hybrid bearing

Picture 01
Picture 01
Picture 02
Drawing 01
Picture 01
Picture 03
rohs
cleanroom
  • Material: aluminium
  • Material sliding element: iglidur® J
  • Roller bearing
Part No.
size
Floating bearing
Preload housing [N]
Dimensions
Fold
05183da2-7c32-4a4b-a39c-8be2c6da5c03-origin-WJRM-01-10-ES-FG_2
Floating bearing
none Unfold Fold
A1 [mm]
16.5 Unfold Fold
A3 [mm]
6.5 Unfold Fold
B [mm]
26 Unfold Fold
B2 [mm]
2.5 Unfold Fold
C1 [mm]
35 Unfold Fold
C3 [mm]
22 Unfold Fold
H [mm]
18 Unfold Fold
G1 [mm]
27 Unfold Fold
Thread K2
M6 Unfold Fold
Thread K3
M5 Unfold Fold
General properties
Fold
size
10 Unfold Fold
Design
round Unfold Fold
Material
aluminium Unfold Fold
Anti-Reflex
Mechanical properties
Fold
Static load capacity Coy [N]
250 Unfold Fold
Dynamic load capacity Cz+ at total running distance of 10 km [N]
250 Unfold Fold
Dynamic load capacity Cz+ at total running distance of 100 km [N]
90 Unfold Fold
Dynamic load capacity Cz+ at total running distance of 200 km [N]
50 Unfold Fold
F · v max.
50 N ⋅ m/s Unfold Fold
Preload housing [N]
0 Unfold Fold
