Clevis joint with pin and circlip, GARMK, igubal®
- Male thread on the right
- igumid® G material
- Lightweight
- High rigidity
- Absolute corrosion resistance
- High tensile force
- Can be combined with rod ends of the dimensional series E
- Vibration-dampening
- Noise-dampening
Part No.
Ø d1 [mm]
g [mm]
thread d2
Dimensions
Fold
thread d2
M10 Fold
Ø d1 [mm]
10 Fold
g [mm]
19 Fold
l1 [mm]
30.3 Fold
l2 [mm]
69 Fold
h1 [mm]
57 Fold
b1 overall length [mm]
10 Fold
a1 [mm]
20 Fold
a2 [mm]
20 Fold
b [mm]
1.3 Fold
General properties
Fold
Thread direction
Right-hand thread Fold
Dimensional series
E, according to DIN 71752 Fold
Weight [g]
15.14 Fold
