drylin® N miniature guide NS-01-12

Certificates and standards (icons)

Short and long carriages, also with pretension. Adhesive rail assembly possible
Extremely lightweight, easy assembly without drilling thanks to adhesive tape
Lightweight construction: rail (500mm) and carriage (50mm) together only weigh 45g
The carriages are PTFE-free and PFAS-tested thanks to iglidur® JPF

Part No.

NS-01-12

Hole pattern rail

Standard drilling pattern

Dimensions

a [mm]

12 Unfold Fold

C4 [mm]

30 Unfold Fold

C5/C6 (min.) [mm]

10 Unfold Fold

C5/C6 (max.) [mm]

24.5 Unfold Fold

h [mm]

4.5 Unfold Fold

h1 [mm]

1 Unfold Fold

Mechanical properties

Geometrical moment of inertia ly [mm4]

494 Unfold Fold

Geometrical moment of inertia lz [mm4]

47 Unfold Fold
