igumid® P150, filament for 3D printing
- Carbon fiber-reinforced material for structural components
- High strength and stiffness, temperature-resistant up to 100 °C
- Easy to process on all standard 3D printers with a hardened nozzle
Material profile for Bambu Lab X1/P1/H2/P2 available for download
Part No.
Filament diameter
Net weight [g]
General properties
Fold
Density [g/cm³]
1.4 Fold
Max. total moisture absorption [Wt.- %]
0.3 Fold
Colour
black Fold
Mechanical properties
Fold
Modulus of elasticity printed flat [MPa]
4700 Fold
Flexural strength printed flat [MPa]
87 Fold
Dimensions
Fold
Spool width [mm]
67 Fold
Inner diameter spool [mm]
52 Fold
Outer diameter spool [mm]
200 Fold
Weights
Fold
Net weight [g]
750 Fold
Physical And Thermal Properties
Fold
Lower application temperature [°C]
-30 Fold
Max. short-term application temperature [°C]
125 Fold
Max. long-term application temperature [°C]
100 Fold
Processing Instructions
Fold
Nozzle temperature (max.) [°C]
280 Fold
Nozzle temperature (min.) [°C]
260 Fold
Bed temperature (max.) [°C]
80 Fold
Bed temperature (min.) [°C]
70 Fold
Requirements
Fold
Suitable for glue stick
Mould-free according to DIN EN ISO 846 Procedure A
Food industry
Properties and approvals
Fold
Flame retardant
PFAS-tested
